304 investment casting

Baoding Guokun, with 25 years casting experience, can produce various stainless steel investment casting for various industries. Lost wax investment casting process can produce complex parts that are near-net shape. The stainless steel lost-wax casting parts manufactured by Baoding Guokun is with complex shapes, tight and accurate tolerances that have a standard of +/-0.005, fine surface finish 125 μin (3.2 μm Ra), minimal machining to reduce time and cost and cost-effective. Please mail your inquiry to gina@guokuncasting.com to get a quotation.

Steel Castings Tags:

Description

Baoding Guokun, with 25 years casting experience, can produce various stainless steel investment casting for various industries. Lost wax investment casting process can produce complex parts that are near-net shape. The stainless steel lost-wax casting parts manufactured by Baoding Guokun is with complex shapes, tight and accurate tolerances that have a standard of +/-0.005, fine surface finish 125 μin (3.2 μm Ra), minimal machining to reduce time and cost and cost-effective.

Stainless steel is a type of low-carbon steel that is resistant to corrosion and rusting. It is made from iron, chromium, and other elements, such as nickel, carbon, molybdenum, and nitrogen. The chromium content in stainless steel is at least 10.5%, which creates a chromium oxide layer on the surface that protects the material from further oxidation.

Stainless steel has many properties, including corrosion resistance, durability, temperature resistance, recyclability, maintenance, modern appearance, high tensile strength, good ductility and high hardness. The stainless steel can be used in many different industries, such as automotive, aircraft, construction, marine, medical, food, etc.

The common stainless steel grades

stainless steel alloys
Grades

Chemical Composition

Mechanical Properties

C

 Cr Ni Mo Tensile Strength
MPa		 Yield strength
Mpa

Elongation
%
304

≤0.08

 18 ~ 20 8 ~ 11 – ≥520 ≥205

≥45
304L

≤0.03

 18 ~ 20 8 ~ 12 – ≥480 ≥175

≥45
316

≤0.08

 16 ~ 18 10 ~ 14 2 ~ 3 ≥520 ≥205

≥45
316L

≤0.03

 16 ~ 18 10 ~ 14 2 ~ 3 ≥480 ≥175

≥45
410

≤0.12

 11.5 ~ 13.5 ≤0.75 – ≥440 ≥205

≥20
430

≤0.12

 16 ~ 18 ≤0.75 – ≥450 ≥205

≥22

The most common stainless steel alloy is austenitic stainless steel, particularly Grade 304 and Grade 316, which is a mixture primarily composed of Cr and Ni, offering good corrosion resistance and excellent formability, making them widely used in various applications.

stainlesssteelpump

Baoding Guokun Investment casting process steps for 304 OEM casting parts:

No. Steps Details
1 Patterns Makings Creating a wax mold of the desired stainless steel pump impellers, and then adding sprues to the wax model to create a tree-like structure.
2 Shell Building Coating the wax pattern with a layer of fire-resistant paint, and then to be sprinkled with sand, so after a period of hardening, the surface will form a layer of fire-resistant thin shell.
3 Dewaxing Removing the wax, the shell is placed into an oven, melting the wax so that it can run out of the shell.
4 Pouring Pouring the molten stainless steel into the shell, and waiting for solidification under room temperature.
5 Post treatment After cooling, knock the shell and cut the sprue gate by grinding machinery to achieve net shape impeller castings. Then shot blasting to move mill scales to assure the smooth casting surface.
6 Machining CNC Machining & Balancing
