Cast iron butterfly valve body

Part Name: cast iron butterfly valve body

Metal: Ductile iron ASTM A536 Grade 65-45-12

Metal casting: Sand casting process

Surface treatment: Sand blasting, painting, power coating or as per your requirements

Lead time: 30 days after getting your order

Payment term: T/T

Baoding Guokun, a famous China investment casting factory, can produce various casting valve components, valve body, valve disc, valve seat, hand wheel and other valve parts as per your drawings. If you need cast ductile iron valve bodies, please contact gina@guokuncasting.com to get the quotation.

Sand Casting, Valve Castings Tags: valve body

Description

Guokun Casting, of Baoding Hebei is an ISO 9001-2008 registered iron and steel foundry & supplier of high quality carbon steel, cast iron and machined castings used in power, mining, railway, agricultural, tillage, truck, automobile, pump, valve, motor, pipe fittings and gear industry. Baoding Guokun has been specialized in the designing and manufacturing of various valve components for ball valve, gate valve, globe valve, butterfly valve, through conduit gate valve, knife gate valve, bellow valve, strainers and flow control components.

What is the common material for valve body?

Valve bodies can be made from a variety of materials, including metals and non-metals, depending on the fluid, pressure, tempreature and other factors. Baoding Guokun can cast the customized valve bodies as per the following metals:

Valve Body material
Cast iron valve body	more suitable for low pressure valves with working temperature between -15~200 °C and nominal pressure no more than PN16.
Ductile iron valve body	Stronger and tougher than gray cast iron valve body, making it more suitable for medium and low pressure valvess with working temperature between –30°C to 350°C and nominal pressure no more than PN40.
Carbon steel valve body	Suitable for water, steam, air, hydrogen, ammonia, nitrogen and petroleum medium. WCB valve body or WCC valve body is suitable for medium and high pressure with working tempearture range of –30°C to 425°C and nominal pressure can reach up to PN420.
Austenitic stainless steel valve body	Suitable for the valve of corrosive medium with working tempeature range of –196°C to 816°C. SS304 and SS316 is durable and resistant to corrosion, making it a good choice for a wide range of applications.
Cast copper alloy valve body	used in valves for oxygen and sea water pipelines, with a working temperature range of –273°C to 200°C.

Baoding Guokun also can produce bronze valve body, brass valve body, alloy steel valve body as per your drawings or design.

What is metal casting process of valve body?

Sand casting: Sand casting process is an industrial metal casting process that involves creating a mold from sand and pouring molten metal into it, generally used to cast the shaped parts of nearly any design, including large parts and those with internal passages. Baoding Guokun can produce various sand cast parts in cast iron, ductile iron, gray iron, low-carbon steel, mild steel, alloy steel for pump, valve, agriculture, railway, road, forklift, tillage, mining, automotive, medical, food, and aircraft, etc

Sand casting process for ductile iron parts

baoding Guokun mold for sand casting cast iron valve components

Investment casting is an industrial metal casting process based on lost-wax precision casting, generally used for producing complex-shaped metal components that require tighter tolerances, thinner walls and better surface finish than other sand cast parts. Baoding Guokun can produce various investment casting parts in low-carbon steel, mild steel, alloy steel, stainless steel for pump, valve, agriculture, railway, road, forklift, tillage, mining, automotive, medical, food, and aircraft, etc.

A High Quality China Foundry！

With a montly capacity of 10,000kgs and with more than 15 years of experience ensure the short delivery and the highest valued iron & steel casting parts.

sand casting workshop

Pump casting, Valve casting, agricultural casting, aircraft casting, railway casting, road casting, motor casting, mining casting, power generation investment casting, Medical casting, marine industry casting
